NAD C338 Hybrid Digital DAC Amplifier

Line In, Speaker Out

Continuous Output Power into 4 Ohms and 8 Ohms (Stereo)

>50W (at rated THD, 20-20kHz, both channels driven)

IHF Dynamic Power

8 Ohm 80W
4 Ohm 150W
2 Ohm 210W

THD (20Hz-20kHz)

<0.03% (250mW to 50W, 8 Ohm and 4 Ohm

Signal/Noise Ratio

>98dB (A-weighted, 500mV input ref. 1W out in 8 Ohm)

Clipping power

>60W (at 1kHz 0.1% THD)

Peak output current

>18A (in 1 Ohm, 1 ms)

Damping Factor

>300 (ref. 8 Ohm, 20Hz to 6.5kHz)

Frequency Response

±0.3 dB (20Hz-20kHz)

Channel Separation

1kHz >75dB
10kHz >65dB

Input Sensitivity (For 50W in 8 Ohm)

Line In: 380mV, Digital In: 18% FS

Sample Rate

Up to 24 bit/192kHz

Phono In, Speaker Out

THD (20Hz-20kHz) (Stereo)

<0.3% at 50W out

Signal/Noise Ratio

>82dB (200 Ohm source, A-weighted, ref. 500mV out)
>76dB (MM cartridge source, IHF A-weighted, ref. 500mV out)

Input Sensitivity

4.1mV (ref. 50W 1kHz 4 Ohm out, Volume maximum)

Frequency Response

±0.3dB (20Hz-20kHz)

Input Impedance

47 kilohm + 100pF

Maximum Input Signal

>80mVrms (ref. 0.1% THD)
